Name: Monitor Audio CT180-T2 Trimless 100 8" Stereo In-Ceiling Speaker (Each)
SKU: 81576

Features dual, independent, pivoting 1-inch C-CAM tweeters and an 8-inch MMP II dual wound voice coil bass driver, for high performance stereo sound from a single speaker. Ideal for bathrooms, hallways, or any area where space does not allow for stereo pairs.

2-way design with pivoting C-CAM tweeters (15 degrees of play).

High overall efficiency.

High frequency level adjustment ( /-3dB).

Audio match with CP range 100 models, Climate 10, Bronze BX and Radius Series hi-fi speakers.

Our innovative Tri-Grip fixing system is easier to install than conventional clamping schemes but provides three times the surface area and a better surface seal, maximising bass response and mid-range clarity.

Magnetic and easily removable steel grille.

Paint-able surface to blend with the living environment. Additional scrim material is provided for trouble free painting.

Splash and humidity proof for installation in shower room or pool areas.

Features dust protection cover that is designed to prevent the ingress of dirt or dust into the driver and crossover.

Specs

Frequency Response
50 Hz - 25 kHz

Impedance (Nominal)
6 6 Ohms

Sensitivity (1W@1M)
90 dB

Maximum SPL
111.6 dBA

Power Handling (RMS)
120 W

Recommended Amp Requirements
30 - 120 W

Drivers Unit Complement
8 MMP II cone bass driver 2 x 1 C-CAM pivoting gold dome tweeters

Adjustment Controls
HF Level Switch ( 3dB / 0dB / -3dB)

Overall Diameter:(including grille)
285 mm (11 1/4 inch)

Overall Depth:(including grille)
125 mm (4 15/16 inch)

Cut Out Diameter
247 mm (9 3/4 inch)

Mounting Depth
121 mm (4 3/4 inch)

Fixing Type
3 position Tri-Grip dog leg fixings

Construction Material
Mineral Filled ABS Plastic

Pre-Construction Bracket
CB8 (Green)

Weight
3kg (6lb 10oz)
